Magnetic Power Cord EMI Clamp Ferrite Cable Clip Split Suppression Cores

  • September 23. 2022

Coilcore focus on EMC anti-interference components R&D, main products including EMI Filter, EMI Ferrite Core, the amorphous magnetic inductance series and EMC shielding material etc.

The snap-on ferrite cores are superb at reducing electro-magnetic interference and filtering out high-frequency noise pulses to improve signal integrity.

Our snap-ring type EMI clip core made of plastic housing & ferrite core, the housing with self-adaption clip, which can mount on cables tightly, and work for a super long lifespan.

Our material with excellent quality, reference details as below:

No.

PRODUCT

Description

Supplier

Main substance

1

MnZn core

ID3.5/OD10-L20 with 2 halves cores

CAREFUL

Fe2O3 ,MnO, ZnO

2

Plastics case

ID3.5/OD13-L25.2 with self -lock

ChaoXingSheng

PA66-101L ,Black sand

Nylon PA66-101L NC010

DuPond

Polyamide

Black sand

S CARBON

Carbon black , Polymer assistant



No.

PRODUCT

Description

Supplier

Main substance

1

NiZn core

ID9/OD16-L28 with 2 halves cores

CAREFUL

Fe2O3 ,NiO, ZnO ,CuO

2

Plastics case

ID9/OD19.5-L35 with self -lock

ChaoXingSheng

PA66-101L ,Black sand

Nylon PA66-101L NC010

DuPond

Polyamide

Black sand

S CARBON

Carbon black , Polymer assistant



These assemblies are available in four ferreite material classes to suppress differential or common-mode conducted EMI from 1MHz into GHZ region.



Clamp type design make installation easily. You dont need cut-off line, just clip it on the round cable or flat cable directly.The cylinder can be dismountable, and the port has the elastic clip faster. Closer to where the electromagnetic source is, the more effectively to improve the signal quality of audio & vedio. The clip-on type design doesnt cause distortion of the transmitted signal and wont affect audio, video & picture quality.



Round cable snap-its can easily accommodate round cable or bundled wires with diameters from 2mm to 15mm. It can improve the electromagnetic field around the solenoid, thus avoiding outside interference.



Main Application:

The Clip Suppression cores help reduce EMI ,which popular used in household appliances, AC power lines, computer peripherals, digital camera, USB cables, mouse cable, keyboard cable, headset cable, data cable, firewire, phone, power cord, coaxial, audio, video cables,internal cables between PC boards and data connectors, etc.
